Gbos 3W 5W Mini Portable Underwear Fabric UV Laser Engraving Marking Printing Machine

GBOS 3W 5W Cheap Small Mini Portable Underwear Fabric Washing Mark Elastic Band UV Laser Engraving Marking Printing Machine



Portable UV Laser Marking Machine



Due to the extremely small focus spot and the small processing heat-affected zone, the ultraviolet laser can perform ultra-fine
marking and special material marking. It is the first choice for customers who have higher requirements for marking effects. The
marking material range includes all plastics, all glass, most metals, wood materials, leather, ceramics, etc.

Product Parameters



UV Laser Marking Machine Technical Parameters
Peak Laser Power	3W/5W/8W/10W
Wavelength	355nm
Repetition Precision	0.01mm
Marking Depth	≤0.5mm
Marking Speed	<8000mm/s
Cooling Mode	Water Cooling
Graphic Formats Supported	PLT,DST,AI,DXF,BMP,JPG,CAD,CDR,DWG
Operating temperature	10ºC-35ºC
Warranty	1 Year
Beam Quality	<2M2
Laser Pulse Frequency	20-200Khz
Humidity	5% to 75% (Free of Condensed Water )
Gross Power	<1200W
Min.Line Width	0.02mm
Min.Character	0.5mm
Power source	AC110V/220V± 10%, 50/60HZ
Processing Area	50*50mm/110*110mm/175*175mm/200*200mm(Optional)
System Composition	Laser,Controller,Imported Galvo scanner ,Lens ,Computer
